Prepared Food Packaging
Start with the meal, the tray and how the pack will be used. Our Hybrid Pro T680 tray sealer lists ready meals and runs seal-only, MAP and VSP packs on one machine.
Typical route: tray supply → product loading → T680 tray sealing → inspection and labeling → case packing
What Are You Packaging?
Ready meals and prepared foods in sealed trays. The application page goes deeper into the challenges, the route and the test.
One sealer, many mealsMeals can share the same tray sealer but still need different loading, flange and sealing conditions.
Explore Prepared Food Tray PackagingWhat changes the setup
Single or multi-compartment tray
Sauce or oil near the flange
Fill level
Tray material and flange
Top film and peel
End use: chilled, frozen or reheated
Common Prepared Food Packaging Challenges
Five things that decide how a prepared food tray line performs.
Sauce on the flange
Sauce, oil and crumbs near the flange stop the film from sealing cleanly.
Fill level
Overfilled trays push product into the seal area.
Compartment trays
Each compartment is filled separately, and the film often has to seal along the dividers too.
Tray distortion
Heat and handling can bend trays and weaken the seal.
End use
Microwave or oven use depends on the tray and film you choose, not on the tray sealer.
Recommended Packaging Route
Tray supply, loading and sealing are planned together, then matched to the meal.
- 01
Tray Supply
Empty trays to the line
- 02
Product Loading
Meals placed in the trays, with a clean flange
- 03
T680 Tray Sealing
Seal-only, MAP or VSP
- 04
Inspection and Labeling
Checkweighing and labels
- 05
Case Packing
Trays into cases
Tray supply, loading, inspection, labeling and case packing are integrated around the T680.
Packaging Mode and Machine Fit
Choose the mode for the meal and its end use. All three run on the T680.
Seal-Only
Lidding film sealed onto the tray without changing the atmosphere.
Up to 25 cycles/min*MAP
Vacuum, then gas filling with an O₂ / CO₂ / N₂ mix. Residual O₂ below 0.5%.
Up to 20 cycles/min*VSP
Vacuum skin packaging, where the meal's shape, the tray and the film suit it.
Up to 12 cycles/min*
*Machine maximum. Actual output depends on product, tray, film, gas mixture and tooling.
Why the T680
Ready meals are one of the T680's listed applications, and one machine covers all three modes on plastic or paper-based trays. Detailed specifications are on the machine page.
View T680Define Sustainable Good Output
A prepared food tray line runs at the pace of its slowest stage, often loading or a clean seal, so we check every stage instead of quoting the sealer's top speed.
Trays per cycle depend on your tray, compartments and tooling. We set the final line target from product tests and agreed FAT conditions.
Request a Packaging Test- 01
Tray supply
A steady supply of empty trays
- 02
Loading
Enough filled trays per minute, with a clean flange
- 03
Sealing
A stable seal cycle, with vacuum and gas for MAP
- 04
Inspection
Enough accepted, labeled trays per minute
- 05
Case packing
Enough cases per minute at the trays per case you need
Test With Your Meal
Send a sample or the product details. We run them before the final configuration is fixed. The test is free; you cover the shipping of your samples.
What to send
Meal sample or details
Tray sample or drawing
Single or multi-compartment
Top film and peel requirement
Packaging mode
End use
Required output
What the test checks
Fill level and flange cleanliness
Product in the seal
Tray distortion
Seal appearance
Peel, where required
Trays per cycle with your tooling
Sustainable good output
Photo: sealed tray from a T680 test run in our workshop.
Related Pages
The machines, package formats, complete line and services behind this industry.
Which machine is used for prepared food?
The Hybrid Pro T680 tray sealer, which lists ready meals and runs seal-only, MAP and VSP packs.
Can the packs go in the microwave or oven?
That depends on the tray, film, seal and food process, so it cannot be promised from the sealer alone. It has to be confirmed for your tray and film.
Can the T680 seal multi-compartment trays?
Compartment trays need tooling and seal checks for each layout, so we test them with your tray before you order.
How many trays per minute can the T680 seal?
It depends on the tray size, the tooling and the mode. Standard tooling seals 4 trays per cycle, at up to 20 (MAP), 12 (VSP) or 25 (seal-only) cycles per minute. Your output is confirmed with your tray and tooling.
Which mode should I choose?
Seal-only where no gas is needed, MAP where the meal needs a protective atmosphere, and VSP where the meal's shape, the tray and the film suit it.
Start With Your Product
Send the meal, tray, film, packaging mode, end use and required output. We use them to define the T680 setup and the test plan.
- 01Meal
- 02Tray
- 03Film
- 04Output
We reply within 1 working day.
